2 Gangs Zigbee Switch Module

This is 2 gangs Zigbee Switch Module. You can choose the module has or has no neutral wire according to yur needs. The devices connected to our smart switch module can be linked to your mobile phone by Zigbee signals. Then you can control 2 different channels by one mobile app.

Different Types Of 2 Gangs Zigbee Switch Module

QS-Zigbee-S04-2C-LN

  • 2 Gangs Smart Zigbee Switch Module with neutral wire

  • Voltage 100-240V AC

  • Max. load: 2X1150W

  • Dims (WxDxH): 46x46x18mm

  • With reset key

QS-Zigbee-S04-2C-L

  • 2 Gangs Smart Zigbee Switch Module with no neutral wire

  • Voltage 100-240V AC

  • Max. load: 2x100W for LED

  • Dims (WxDxH): 46x46x18mm

  • With reset key

Parameters Of 2 Gangs Zigbee Switch Module

ProtocolZigbee 3.0
Operation frequency2.4-2.484GHz IEEE802.15.4
Operation temp.-10ºC - +40ºC
Case temp. Tc+80ºC (Max.)
Operation range≤ 200 m
IP ratingIP20
CertificatesCE ROHS
Warranty2 years


Features Of 2 Gangs Zigbee Switch Module

Compatible with most Zigbee 3.0 gateway.
With/Without neutral wire.
2 gangs to control more devices according to your needs.
Mininum brightness is settable.
Easy to install behind the existing switch, keep function of manual switches.
App control is synchronized with the manual switch.
Voice control compatible with Google home and Amazon Alex etc.
Schedule,group, scene, automation functions organizable with other smart home devices,easily achieve home automation.
Accept customer customization for logo, color box. etc.

Quality Standard Of 2 Gangs Zigbee Switch Module

EMC Standard (EMC)

EN 301 489-1 V2.1.1,

EN 301 489-17 V3.1.1,

EN 300 328 V2.1.1 (2016-11),

EN 61000-6-1:2007,

EN 61000-6-3:2007+A1:2011,

EN 62311:2008

EN 60669-2-1: 2004 +A1: 2009+ A12: 2010;

EN 60669-1: 2018; EN 62493: 2015

Safety Standard (LVD)

IEC 60669-2-1:2002 / AMD1:2008 / AMD2:2015,

IEC 60669-1:1998  / AMD1:1999 / AMD2:2006

Radio Equipment (RED)

2014/53/EU – Article 3.1(a), 3.1(b) & article 3.2

RoHS Standard (RoHS)

2011/65/EU, (EU) 2015/863
